AUTOMATION SOLUTIONS
Material Handling is the field concerned with solving the pragmatic problems involving the movement, storage in a manufacturing plant, control and protection of materials, goods and products throughout the processes of cleaning, preparation and manufacturing.
At NICA we offer solutions in material handling through automation for PCB, touch panel, LED, photovoltaic, automotive, semiconductor, GMF, IC substrate and aerospace industries. We believe that through the automation of the material handling for production needs be it on production equipment or its related application, we can help our client achieve a LEAN and efficient total solution.
We fully understand that each client has its own unique requirements and with our in depth knowledge of the applications and industries, our clients can be assured of professional and successful customized automation solutions.
| TECHNOLOGIES |
|---|
In our production solutions for this market following technologies are applied: |
| Automation |
Automation - Loader / Unloader
- Application: Material handling of IC carrier board
- Panel Size: Max:24"*24 Min:10"*10".
- Panel thickness: 0.075mm~3.0mm.
- Production speed: 6 pcs/min.
- Description: Vertical loading and unloading of carrier board, can be designed to fit client’s cassette
- Applications: Materials handling for panels
- Panel Size: Max:24"*24" Min:10"*10".
- Panel thickness: 0.075mm~3.0mm.
- Production speed: 8 pcs/min.
- Description: It can be used with different types of L-RACK
- Application: Materials handling of in process panels
- Panel Size: Max:24"*24 Min:10"*10.
- Panel thickness: 0.075mm~3.0mm.
- Production speed: 8 pcs/min.
- Description: Servo arm panel retriever equipment suitable for handling thin panels
Visual Inspection Solution
Visual inspection is a common method of quality control, data acquisition, and data analysis.
In our production solution for this market, we’ve the following technologies to offer
| Visual Inspection By Operator | Our Fully Automatic Visual Inspection |
|---|---|
| Prolonged Inspection Leading To Fatigue | 24/7 Consistent Operations |
| Long Process Time | Fast And Accurate |
| Human Recording | Auto Recording |
| High Labour Cost | Low Labour Cost |
At NICA we realize the importance of visual inspection to our client and as such we are able to customized a total visual inspection solution. This total visual inspection solution encompasses inspection, verification, classification, data mining and analysis capabilities. Our visual inspection solutions have been and can be adopted in the PCB, touch panel, LED, photovoltaic, automotive, semiconductor, GMF, IC substrate and aerospace industries.
| TECHNOLOGIES | ||
|---|---|---|
In our production solutions for this market following technologies are applied: |
||
| PCB / Substrate Avi | TFF-LCD , Touch Panel AOI | Other Visual Inspection |
PCB / Substrate AVI Solutions
Application: FPC
- Panel size: Max 280mm by 150mm
- Colour line scan camera
- High speed image processing
- Combine CAM file with Golden sample data methods to increase inspection capacity
- Self developed technology catering to needs of customer
- Ease of maintenance
Application: Rigid PCB panels
- Panel size: Max 300mm by 280mm
- Colour line scan camera
- Accurate and precise inspection
- Smart software for part number recognition
Application: HDI/IC Substrate/FPC
- Panel size: Max 300mm by 290mm
- Colour line scan camera
- Simplified mechanism coupled with advance image capturing technology for shorter inspection time
- Stage carrier design enables stable and fast transfer of panels
TFF-LCD , Touch Panel AOI Solutions
Application: LCD/LCM API
- Article size: 7” to 65”
- Inspection items: Uneven defects (Mura), bright/dark spots, bright/dark lines
- Highly precise and accurate. Key features include automatic transfer, auto focus etc.
- Stage carrier design enables stable and fast transfer of articles
Application: FPD/LCD
- Panel size: G2.5~G8.5
- Advance image resolution techniques enabling complete defect detection
- Highly precise and accurate. Key features include automatic transfer, auto focus etc.
- Able to perform CD measurement
- Suitable to use for inspection in the following processes: LCD colour filter, BM, RGB, ITO, MVA, PS and INS
Other Visual Inspection Solutions
Application: LED wafer
- Wafer size: 2” to 6”
- Capable of capturing mask defects, scratches, gold residue, Silicon oxide defects etc.
- Accurate and precise defect detection.
Application: Solar panel and module
- Advance image resolution and CCD enabling complete defect detection
- Come with high speed review and auto defect classification
